SF6 High Voltage 11KV 12KV 24KV 36KV 3 Phase 630A Load Break Switch

SF6 load switch is a high-voltage switchgear that uses sulfur hexafluoride (SF6) gas as insulation and arc extinguishing medium. It is equipped with a simple arc extinguishing device, mainly used for closing and breaking load current, overload current, and can also be used for closing and breaking no-load lines, no-load transformers, and capacitor banks.
The 12 24 35kV SF6 load switch is widely used in the distribution network and substation of the power system to control and protect distribution equipment, and can be used in conjunction with other high-voltage switchgear equipment.
The 12 24 35kV SF6 load switch adopts a fully enclosed structure design, and the interior is filled with SF6 gas as an insulating medium.
The 12 24 35kV SF6 load switch is widely used in the distribution network and substation of the power system to control and protect distribution equipment, and can be used in conjunction with other high-voltage switchgear equipment.

Features
The 12 24 35kV SF6 load switch has the characteristics of compact structure, good insulation performance, reliable operation, and long service life, and the switch can be remotely controlled and monitored.

Operating Environment
1.Ambient temperature: Maximum temperature: + 40 ° C; minimum temperature: -12 24 35 ° C
2.Humidity: Average maximum average relative humidity, saying: ≤ 95%; monthly average: ≤90
3.Altitude: ≤2000 m;
4.Seismic capacity: 8 degrees;
5.Ambient air should not significantly contaminated corrosive, flammable gas, vapor, etc.,
should be no recurrent severe vibration.
6.Annual leakage rate: ≤0.1%.
